LCD Display |
15,6” (16:9) |
Resolution |
1920 (W) x 1080 (H) |
Brightness |
450 cd/m² |
Contrast Ratio |
500:1 |
LCD Color |
16.2M |
Pixel Pitch (mm) |
0.252 x 0.252 |
Viewing Angle (H-V) |
170°/160° |
Backlight MTBF |
50000 hours |
SBC Model |
PPC2MB-ADL-S-R10 |
CPU |
Intel Core i3-12100 |
Chipset |
Intel® H610 |
Graphics Engine |
New Intel® Xe Graphics architecture with SRIOV, Genlock |
Display Output |
1 x HDMI 2.0 |
Memory |
Two 260-pin 3200 MHz dual-Channel DDR4 SO-DIMM (8GB standard
max. 64GB) |
Touchscreen |
Multi-point projected capacitive type |
|
Surface hardness: =7H |
Touch Controller |
Projected capacitive type: EETI 80 |
Storage |
1 x 2.5" SATA HDD bay |
Ethernet |
LAN1: Intel® I225 + LAN2: Intel® I225 |
Expansion |
1 x PCIe Gen4 x 16 slot with x16 Signal |
|
1 x M.2 E-Key 2230 (PCIe Gen3 x1 + CNVIo + USB 2.0) |
|
1 x M.2 M Key 2242/2280 NVMe (PCIe Gen3 x 4) |
|
|
Mounting |
VESA 100mm x 100mm, Panel, Wall, Rack, Stand and Arm |
Construction Material |
Aluminum front cover and sheet metal rear cover |
Enclosure Color |
Black C |
I/O
Ports, Switches and Buttons |
1 x HDMI 2.0 |
|
2 x 2.5GbE RJ45 |
|
2 x USB 2.0 (Type-A) |
|
2 x USB 3.2 Gen1 (Type-A) (5Gb/s) |
|
2 x USB 3.2 Gen2 (Type-A) (10Gb/s) |
|
1 x RS-232/422/485 (RS-485 support AFC) 4 x RS-232
1 x AC input
1 x Power switch
1 x Clear CMOS button
1 x Reset button
1 x AT/ATX switch |
Power Supply |
250W AC input ATX power supply |
|
- Input: 100V~240V AC, 47Hz-63Hz |
|
- Output (max.): 3.3V@6A, 5V@12A, 12V@17A, -12V@0.5A,+5Vsb@2A |
|
Support AT/ATX mode, ErP/EuP Compliant |
Thermal Solution |
Smart fan (2 x CPU fan, 2 x System fan) |
TPM |
Intel® Platform Trust Technology |
Watchdog Timer |
Software Programmable Support 1~255 sec. system reset |
Operating Temperature |
|
(with air flow) |
-10ºC ~ 50ºC |
Storage Temperature |
-20ºC ~ 60ºC |
Humidity |
10% ~ 95%@40ºC, non-condensing |
IP Level |
IP 65 compliant front panel |
Safety and EMC |
CE, FCC Class A, UKCA |
ErP |
ErP 2009/125/EC |
Dimensions(H x W x D) (mm) |
400.7 x 253.90 x 66.45 |
Net Weight |
5.640 kg |
