Analog Output
Output Channels 1
Output Type 0~20mA , 4~20mA and 0~10V
Resolution 12-bit
Accuracy +/-0.1% of FSR
Read Back Accuracy +/-1% of FSR
Zero Drift Current output : +/-0.2uA/°C
Voltage Output : +/-30uV/°C
DA Output Response Time 10ms per channel
Span Temperature Coefficient +/-25ppm/ °C
Programmable Output Slope 0.125 to 1024 mA/second
0.0625 to 512 V/second
Current Load Resistance Internal Power : 500ohms
External 24V : 1050ohms
Photo-Isolation 3750 Vrms
Intra-module Isolation, Field to Logic 3000 VDC
Interface
Interface RS-485
Format N, 8, 1 (details)
Baud Rate 1200 ~ 115200bps
LED Display
1 LED as Power/ Communication indicator
Power
Input +10 to +30 VDC
Power Consumption 1.8W
Environment
Operating temperature -25 to 75°C
Storage temperature -40 to 85°C
Humidity 5 to 95% RH, non-condensing
