Planet WGS-814HP
Planet WGS-814HP
4-Port 10/100/1000T Wall-mount POE
Product nr:
138096
Add to wish list
Description
Hardware Specifications
Network Connector
8-Port RJ45 for 10/100/1000BASE-T
PoE Inject Port
4-Port with802.3at PoE+ injector function (Port-1 to Port-4)
Switch Architecture
Store and forward
MAC Address Table
4K MAC address table with auto learning function
Switch Fabric
16Gbps / non-blocking
Switch Throughput
11.9Mpps@64Bytes
Jumbo Frame
9Kbytes
Flow Control
IEEE 802.3x pause frame for full duplex
Back pressure for half duplex
LED Indicators
Power LED:
Power (
Green
)
PoE Power Usage LED:
15W, 30W, 45W, 60W (
Amber
)
PoE Port:
PoE-in-Use (
Amber
)
LNK/ACT (
Green
)
10/100/1000BASE-T Port:
LNK/ACT (
Green
)
ESD Protection
4KV DC
DIP Switch
Selectable operation modes:
¦ Standard: IEEE 802.3at PoE+ transmission distance of 100m
¦ VLAN: Port-based VLAN
¦ Extend: 25-watt PoE transmission distance of 250m at speed of 10Mbps
Connector
DC power jack with 2.0mm central pole
Power Requirements
48~56V DC, 1.5A (max.)
Power Consumption
70 watts / 239BTU
Enclosure
IP30 metal
Dimensions (W x D x H)
148 x 134 x 24.2 mm
Weight
472g
Installation
Fixed wall mounting, magnetic wall mounting and DIN-rail mounting
Power over Ethernet
PoE Standard
IEEE 802.3at Power over Ethernet Plus PSE
PoE Power Supply Type
End-span
PoE Power Output
IEEE 802.3af Standard
- Per port 48V~56V DC (depending on the power supply), max. 15.4 watts
IEEE 802.3at Standard
- Per port 50V~56V DC (depending on the power supply), max. 30 watts
Power Pin Assignment
1/2(+), 3/6(-)
PoE Power Budget
60 watts (depending on power input)
Max. Number of Class 2 PDs
4
Max. Number of Class 3 PDs
4
Max. Number of Class 4 PDs
2
Standard Conformance
Standard Compliance
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3x Flow Control
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet plus
IEEE 802.3z Energy Efficient Ethernet
Regulatory Compliance
FCC Part 15 Class A, CE
Stability Testing
IEC 60068-2-32 (Free fall)
IEC 60068-2-27 (Shock)
IEC 60068-2-6 (Vibration)
Environment
Operating
Temperature: -20 ~ 60 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
Storage
Temperature: -20 ~ 70 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
