Planet GSD-1022UP
2-Port 10/100/1000T 802.3bt PoE
Product nr:
138091
Add to wish list
Description
Hardware Specifications
Copper Port
8 10/100/1000BASE-T RJ45 auto MDI/MDIX ports
Fiber Port
2 1000BASE-X SFP slots
PoE Inject Port
2 ports with 802.3bt PoE++ injector function (Ports 1 to 2)
4 ports with 802.3af/at PoE+ injector function (Ports 3 to 6)
DIP Switch
PoE power feeding options (Legacy/BT/UPOE) selection
Thermal Fan
1
Power Requirements
AC 100~240V, 50/60Hz, 2.5A max
Power Consumption
Max. 200 watts, 682.4 BTU
Dimensions (W x D x H)
220 x 150 x 44 mm
Weight
1322g
Surge Protection
Differential mode ±2KV Common mode ±4KV
ESD Protection
Contact: ±6KV
Air: ±8KV
Installation
Desktop, Wall-mount or Rack-mount installation
LED Indicators
System:
Power (
Green
)
10/100/1000BASE-T RJ45 interfaces:
10/100/1000Mbps LNK/ACT (
Green
)
1000BASE-X SFP interfaces:
1000Mbps LNK/ACT (
Green
)
PoE interfaces:
PoE-in-Use (
Amber
)
Switching
Switch Architecture
Store-and-Forward
MAC Address Table
4K MAC address table with auto learning function
Switch Fabric
20Gbps
Switch Throughput
13.39Mpps
Jumbo Packet
9K bytes
Flow Control
Back pressure for half duplex. IEEE 802.3x
pause frame for full duplex
Power over Ethernet
PoE Standard
IEEE 802.3af Power over Ethernet/PSE
IEEE 802.3at Power over Ethernet Plus/PSE
IEEE 802.3bt Power over Ethernet Plus Plus/PSE
PoE Power Supply Type
Ports 1 to 2: End-span + Mid-span
Ports 3 to 6: End-span
Power Pin Assignment
Ports 1 to 2: 4 pairs 1/2 (-), 3/6 (+) and 4/5 (+), 7/8 (-)
Ports 3 to 6: 2 pairs 1/2 (-), 3/6 (+)
PoE Power Output
Ports 1 to 2: 95W max.
Ports 3 to 6: 32W max.
Total PoE Power Budget
180 watts
Standard Conformance
EMI Safety
FCC Part 15 Class A, CE
Standard Compliance
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T Gigabit 1000BASE-T
IEEE 802.3x Flow Control and Back Pressure
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
IEEE 802.3bt Power over Ethernet Plus Plus
EEE
IEEE 802.3az
Environment
Operating
Temperature: 0 ~ 50 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
Storage
Temperature: -10 ~ 70 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
