Physical Port

• 1-port 10/100/1000BASE-T RJ45 with IEEE 802.3bt PoE Injector function
• 2 SFP slots, supporting 1000BASE-X and 100BASE-FX transceiver dual mode

Power over Ethernet

• Complies with IEEE 802.3af/at/bt PoE Plus end-span PSE
• 1 IEEE 802.3af/at/bt device powered
• Supports PoE Power up to 95 watts for PoE port
• Provides DC 54V power over RJ45 Ethernet cable to PD with Ethernet port
• Auto-detects IEEE 802.3bt equipment and protects devices from being damaged
  by incorrect installation
• Remote power feeding up to 100m
• IEEE 802.3af/at/bt splitter devices compatible

Layer 2 Features

• Supports auto-negotiation and 10/100Mbps half / full duplex and 1000Mbps
  full duplex mode on RJ45 port
• Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause
  frame flow control (full-duplex)

Hardware

• LED Indicators
• System: Power 1, Power 2, Fault and PoE usage
• Fiber port: LNK/ACT
• 10/100/1000BASE-T port: LNK/ACT, PoE-in-use
• DIP switch: Standard/Legacy mode selection

Industrial Case and Installation

• IP30 metal case
• DIN-rail and wall-mount designs
• 12 ~ 56V DC redundant power with reverse polarity protection and connective
  removable terminal block for master and slave power
• Supports 6000 VDC Ethernet ESD protection
• -40 to 75 degrees C operating temperature
