Interface

• 2 RJ45 interfaces
  • 1-port Data + Power input
  • 1-port Data output
• 2 DC output (4-pin terminal block)
• 1 12V/24V DC DIP switch

Power over Ethernet

• Complies with 802.3bt Power over Ethernet end-span / mid-span PSE
• Compatible with IEEE 802.3bt PoE++
• Backward compatible with 802.3at PoE+ with up to 30-watt power output
• Supports PoE input power up to 70 watts
• Splits the PoE power over RJ45 Ethernet cable into 12V/19V/24V DC output
• Remote power feeding up to 100 meters

Hardware

• IP30 slim metal case
• DIN-rail or wall mount design
• Supports high surge/ESD protection
• -40 to 75 degrees C operating temperature
