Interface
- 8 10/100/1000BASE-T RJ45 copper ports
- 4 10GBASE-X SFP+ slots, compatible with 1000BASE-X and 2500BASE-X SFP
Power over Ethernet
- Complies with IEEE 802.3bt PoE++ type 4 PSE
- Backward compatible with IEEE 802.3at PoE+
- Up to 8 ports of IEEE 802.3bt/at devices powered
- Up to 360-watt PoE budget
- Supports PoE power up to 95 watts for each PoE port
- Each port supports 48~54V DC power to PoE powered device
- Auto detects powered device (PD)
- Auto detects IEEE 802.3bt equipment and protects devices from being
damaged by incorrect installation - Circuit protection prevents power interference between ports
- Remote power feeding up to 100m
Industrial Hardened Design
- IP30 aluminum case
- DIN-rail and wall-mount designs
- Fault alarm for power input failure
- Supports 6KV DC Ethernet ESD protection
- -40 to 75 degrees C operating temperature
- 4 real-time PoE power usage indicators
- 48~54V DC redundant power with reverse polarity protection
Layer 2 Switching
- Features Store-and-Forward mode with wire-speed filtering and forwarding rates
- IEEE 802.3x flow control for full duplex operation and back pressure for half duplex operation
- 16K MAC address table size
- 12K jumbo frame
- IEEE 802.1Q VLAN transparency
- Automatic address learning and address aging
- Supports CSMA/CD protocol
