POC-17C-ULT3-C/PC/4G-R10 17" Panel PC
POC-17C-ULT3-C/PC/4G-R10 17" Panel PC
IEI/Celeron 3855U/4GB/PCTouch
Product nr:
124266
Add to wish list
Datablad
Description
Support
Spec Item
Description
Communication
Bluetooth
V4.1 (M.2 2230 A-E key module)
Wi-Fi
IEEE 802.11 a/b/g/n/ac 2T2R module
Environment
Humidity
10% to 95% (non-condensing)
IP Level
IP 65 compliant front panel
Operating Shock
Operating Shock: 5G peak acceleration (11ms duration)
Non-Operating Shock: 15G peak acceleration (11ms duration)
Operating Temperature
0°C~40°C
Operating Vibration
1G
Storage Temperature
-20°C~60°C
Function Key
Function Key
1 x LCD on/off
1 x Brightness up
1 x Brightness down
1 x Volume up
1 x Volume down
1 x Touch lock button for cleaning
Combinations:
1 x Lock/Unlock OSD
1 x Power on/off
I/O Interface
Audio
2 x 2W speaker
Expansion
1 x PCIe Mini reserved
I/O Ports and Switches
1 x RJ-11 for barcode module (1D/2D)
4 x USB 2.0 (2 for side)
4 x USB 3.0 port
1 x HDMI output
2 x GbE LAN port
1 x RS-232/422/485
1 x 12~28V DC jack
LCD
Backlight MTBF
30000 (LED backlight)
Brightness (cd/m2)
350
Contrast Ratio
1000:1
LCD Color
16.7M colors (RGB 6-bit)
Pixel Pitch (mm)
0.264 (H) x 0.264 (V)
Resolution
1280 (W) x 1024 (H)
Size
17” (5:4)
Viewing Angle (H-V)
170°(H) / 160°(V)
Other Features
Ambient Light Sensor
Ambient light sensor for panel brightness adjustment
Camera
2-megapixel CMOS front-facing
Microphone
digital microphone
RFID Reader
Optional: Mifare 13.56 MHz card reader
System Cooling
Fanless
Physical Characteristics
Construction
ABS+PC plastic with anti-bacterial material
Dimensions (LxWxH) (mm)
435 x 376 x 64.5
Mounting
Wall, Stand and Arm VESA 100mm x 100mm / 75mm x 75mm
Power
Input
12V~28V DC input
Power adapter
120W medical power adapter: Input: 100V~240V AC, Output: 19V DC
System
Cooling method / System Fan
Fanless
CPU
Intel® Skylake-ULT platform Core™ i5-6300U and Celeron® 3955U
Memory Max.
Two 260-pin 2133/1866 MHz dual-channel DDR4 non-ECC unbuffered SO-DIMMs
(system max. 32GB)
Storage
2 x 2.5” SATA 6Gb/s HDD bay
1 x mSATA reserved (M.2 interface)
Touch
Touch Controller
ILITEK
Touch Screen
Projected capacitive type with USB interface
Surface Hardness: 6H
Weight
Weight
5.8 Kg
LED Function
LED Function
RFID indicator LED
