SPL-101GT-ATOring 1-port Gigabit PoE Splitter

Overview

SPL-101GT series is a high power PoE Splitter for use in Power over Ethernet systems. With Ethernet Input (data + power) port and Output (data only) port, SPL-101GT may split power from existing LAN cable and convert up to 24VDC/1.125A or 12VDC/1.6A(SPL-101GT-12V) for power hungry applications such as Wireless APs, Security cameras and IP Phones. The internal current limit, short-circuit and overload protection are implemented for use as a DC power supply.

Features

• Fully compliant with IEEE802.3at standard
• Supports 10/100/1000Base-T(X) for PoE In and Data Out
• Power Isolation and Short Circuit Protection for Power Output
• Auto protection for Over Voltage Power Input
• Supports Power Outputs up to 27Watts Max.
• IP-30 Rugged Case Design
• DIN-Rail and Wall Mount Design
