INDUSTRIAL PC

iNA100 DIN-Rail Network Appliance

x5-E3930/4x LAN/12VDC

Product nr: 130503
iNA100 DIN-Rail Network Appliance x5-E3930/4x LAN/12VDC
Datasheet
Form Factor
  • DIN-rail, Wall mount (optional)
CPU
  • Intel® Atom® x5-E3930 processor (Apollo Lake)
Chipset
  • SoC integrated
System Memory
  • 1 x DDR3L-1866 SO-DIMM, up to 8GB non-ECC/ECC memory
BIOS
  • AMI
Ethernet
  • 4 x 10/100/1000 Mbps (Intel® i211)
Storage
  • 1 x half sized mSATA (occupied 1 x PCI Express Mini Card slot)
  • 1 x Internal 2.5" SATA drive (9.5 mm height)
Expansion
  • 1 x Half-size PCIe Mini Card slot with SATA/USB signal
  • 1 x Full-size PCIe Mini Card slot with USB signal
I/O Interface
  • 1 x RS-232
  • 1 x RS-232/422/485
  • 4 x 1GbE RJ-45
  • 2 x USB 3.0
  • 1 x HDMI
  • 2 x Tact switch (1 x reset button, 1 x GPI button)
Power Supply
  • 1 x 2-pin terminal block 12V
Others
  • LAN Bypass (one pair)
Watchdog Timer
  • 255 stepping for system reset
Dimensions
(H x W x D)
  • 150 x 120 x 54 mm (5.9" x 4.72" x 2.13")
Operating Temperature
  • -20°C to +60°C (-4°F to +140°F)
Weight (net/gross)
  • 1.1 kg (2.43 lb)/2.0 kg (4.41 lb)
OS
  • Win 10, Linux (Yocto project)
Certifications
  • FCC class B/CE class B
