Kontakt oss for tilbud på ferdig konfigurert løsning med ram, lagring, OS etc.
| LCD Panel | - 12.1" XGA TFT LCD with LED backlight
- 500 nits (XGA)
- 1024 x 768 (XGA)
|
| CPU | - Intel® Celeron® Processor J1900 2.0 GHz
|
| Chipset | |
| System Memory | - 1 x 204-pin SO-DIMM DDR3L up to 8 GB
|
| BIOS | |
| COM | |
| USB | |
| Ethernet | - 2 x 10/100/1000Mbps (Intel® i210IT)
|
| Display | |
| Audio | |
| Storage | - 1 x 2.5" SATA HDD
- 1 x CFas™ or mSATA
|
| Expansion | - 1 x Full-Size Mini PCI Express Mini Card with mSATA
- supported
- 1 x Full-Size Mini PCI Express Mini Card with SIM Slot
|
| Others | |
| Touchscreen | |
| Front Bezel | - IP65, NEMA 4 rugged protection, plastic front bezel
|
| Power Supply | - 9~36VDC
- 100~240VAC, 60W adapter
|
| Power Comsumption | |
| Watchdog Timer | |
| Operating Temperature | - 0° ~ +50°C (+32°F ~ +122°F) (with W.T. DRAM/HDD in airflow condition)
- 0° ~ +45°C (+32°F ~ +113°F) (with W.T. DRAM/HDD)
|
| Relative Humidity | - 10% ~ 95% @ 40°C; non-condensing
|
| Vibration | - 2G, 5 ~ 500Hz, random for CFas™
|
Dimensions
(W x D x H) | - 327.5 x 52.5 x 261.8 mm (12.9" x 2.07" x 10.3")
|
| Weight (net/gross) | - 2.48 kg (5.46 lb)/3.84 kg (8.46 lb)
|
| Certification | - CE-EMC class A (GOT5120T-834)
- CE-EMC class B (GOT5120T-834-J)
|
| EOS | - Windows® 8, WE8S, Windows® 7, WES 7
|
| Mounting | - Panel mount
- Wall mount
- VESA arm
- Desktop stand
|
